10W SMA Coaxial Attenuator 1db,3db.6db.10db.15db.20db.30db,40db 50ohm 4GHz
- [Return Home] [Go Back]
- 10W SMA Coaxial Attenuator 1db,3db.6db.10db.15db.20db.30db,40db 50ohm 4GHz
Model No.:
TWATS-10W-4GPrice:
1Minimum Order:
1
Product Abstract:
10W SMA fixed attenuator 4Ghzmale to female connector
1db,3db.6db.10db.15db.20db.30db all available
OEM is welcome
- Product Description
Applications: DC-4G, RF SMA 10W rf coaxial fixed attenuator 50ohms
1.10W coaxial fixed attenuator is widely used in below fileds:
A. Mobile Communication Network Optimization and In-door distribution system.
B. Cluster communication, satellite communication, shortwave communication and hopping radio.
C. Radar, electronic navigation and electronic confrontation.
D. Aerospace equipment systems.DC-4G, SMA 10W fixed Attenuator Technical Specifications: NORMINAL IMPENDANCE 50Ω FREQUENCY RANGE DC to 4.0GHz VSWR ≤1.20 POWER RATING 10W TEMPERATURE RANGE -55°C to +125°C Attenuation 3,6,10,15,20,30dB available, and 1-10dB.±0.5dB,15-30dB±1dB
